Stahlwille 714 MANOSKOP, size 2 - electronic indicating and click type torque wrench

Accepts 9x12mm head fittings
4 measuring modes (torque, angle, torque backed up by angle, angle backed up by torque)
High-definition color display with additional side-mounted indicator lights
Torque and angle are simultaneously visible
Freely configurable menu
3 function modes:
- Cut-out
- Peak hold (indicating mode with peak value)
- Track (indicating mode with current value)
Tactile and acoustic trigger signal
Micro USB interface
Bayonet connection for battery compartment
QuickRelease safety lock change system for insert tools
Angle-controlled measurement without a reference arm
Data storage (2500 tightening jobs)
As many as 200 joints can be programmed, in up to 25 preset sequences
Different tolerance limits can be set for each joint
Acoustic and visual assessment of the joint
Tightening torque is automatically corrected if a deviating extension is entered
Immediately reusable after release
Clockwise and anti-clockwise tightening - it may be necessary to refit the insert tool rotated through 180 degrees for anti-clockwise tightening in the cut-out mode
Rapid, accurate setting via keypad (with keypad lock)
Overload protection by means of acoustic and visual signals with a fail-safe system (clockwise)
Automatic notification of the next calibration date, either by the number of joints or the time interval
Safe handling due to ergonomically designed handle (resistant to oils, grease, fuels, brake fluid and Skydrol)
Includes 2 certificates (torque, angle)
Supplied with SENSOMASTER Basic software and USB cable

**Batteries NOT included due to shipping regulations from Germany**
- Requires 4 x AAA/LR03 batteries
- 1.2V micro NiMH rechargeable batteries can be used

Tech Specs.

Size of Insert Tool Carrier (inside square): 9x12mm
Units of measure: Nm, ft-lb, in-lb.
Scale Range: 2-20 Nm, 1.5-15 ft-lb, 18-180 in-lb
Setting/display increments for torque: 0.5/0.1 Nm; 0.5/0.1 ft-lb; 5/1.0 in-lb
Setting/display increments for angles: 0.1 degree
Display deviation value, angle: +/- 1%, +/- 1 digit
Display deviation value, torque: +/- 2%, +/- 1 digit
Weight with box: 805g (1.77 lbs)
Weight of torque wrench: 380g (0.84 lbs)
Length: 226 mm (9.0 in.)
Storage: sturdy plastic case

Manufacturer Part #: 96500902
